Burke Bariatric Heavy Duty Hospital Beds Burke

BURKE TRI-FLEX

~ 1,000 Lb. Capacity

~ 2 Widths in One

~ Compact "Fold & Roll" Design

~ Multiple Positioning

~ Low Air Loss Surface Option

~ Integrated Scale Option

~ State of the Art" Low Voltage
Actuator System

Burke Bariatric Heavy Duty Hospital Beds- Burke is Burke Triflex and Burke Bariatric Treatment System II Heavy Duty Hospital Beds,1,000 lb. weight capacity, patient bad, caregiver bed, multiple positioning

Easy Patient Egress Burke Bariatric Heavy Duty is triflex hospital adjustable

Heavy Duty BAriatric Bariatric Heavy Duty is Hospital Bed

Facts & Specifications

- Heavy Duty Hospital Bed

- 1,000 lb. weight capacity

- Low air loss/alternating pressure surface option

- Integrated scale option

- Pressure reducing 5" foam mattress system

- Adjustable, powder coated half side rails

telescoping to 6"

- Oak finish head & foot boards

- Modular electronics pkg:

Approved to CSA, UL & CE standards

- Low power consumption 1.6 amps

- Hospital grade plug

- Heavy duty 6" x 1 1/4" Steer & Lock casters

- Length: End to End 92 1/2" (7’8 1/2")

- Patient surface length 84" (7’) With extension 96" (8’)

UL 60601

IMPORTANT SAFETY AND REGULATORY INFORMATION

FEDERAL REGULATIONS REQUIRE UL TESTING / LISTING

FOR HOSPITAL BEDS

Tri-Flex II Questions

What is the weight capacity?

1,000 lbs.

Can you have a 1,000 lb. patient on the bed and the trapeze set?

Yes.

What are the benefits of the “Fold & Roll” design?

- 1 person can easily deliver the bed.
- Takes up 1/3 of the space of a regular design bed whether in transit or in storage.

What comes standard with the bed?

- 1,000 lb. Capacity Frame with extra width capability from 37” to 48”
- “Fold & Roll” Design for 1 person delivery system and easy storage
- Fully electric with Hi-Lo, Trendelenberg/Reverse Trendelenberg, Full Head & Knee Gatch Adjustment
- 1 Hand Control
- 2 Head Side Rails
- 7” pressure reducing foam mattress with accompanying sections for extra width capability
- Molded Plastic Head & Foot Boards
- CPR Release & Battery Back Up

How do you make the patient surface width wider or narrower?

Sections along each side of the bed release and slide out or in to lock into place.

How does that work with the foam pressure reducing mattress?

The foam mattress is a 3 piece arrangement that offers side bolsters for the wider position. They are removed when reducing the patient surface width to transfer the patient on the bed to a new location.

Can the scale option be installed in the field?

No. The integrated scale system must be installed at the factory.

How wide and long is the patient surface of the bed?

37” Wide to 48” Wide and 86” Long

How current is the Tri-Flex II’s UL Certification?

The Tri-Flex II has passed the UL 60601 Certification testing in its entirety. Many bariatric beds in the market may have only parts of the bed certified to one standard or another, for example, only the electrical package may have this level of safety assurance. The Tri-Flex II has passed the UL 60601 testing as a complete and total bed. Also known as 2601, this is the industry’s latest
and most stringent compliance classification and will be around for years to come.
