10 Reasons to Buy a Hospital Bed from Latexpedic®

What does 46 Years of Experience Mean to You?

The Right Hospital Bed.

  1. Price: We offer the World's Lowest Prices Guaranteed!
  2. Quality:We have a andquot;Aandquot; with the Better Business Bureau
  3. Guarantee: We guarantee our Prices, Selection and Service
  4. Service: Lifetime Service Commitment
  5. Selection: We have the largest selection with the specialists who know what is right for you.
  6. Mattresses: Not only do we manufacture our own highly rated mattresses, we also are authorized dealers for the following manufacturers:
  7. Bariatric: Our specialists have been in the bariatric field for over 25 years. Only this experience can guarantee you the expertise you need in your selection of the Right Equipment.
  8. All Sizes: Whether you are 6' 4andquot; or 4' 10, weight 80 lbs or 400 lbs, we have the bed that will fit you!
  9. All Manufacturers:We Are the Authorized Dealers of Over 50 Different Electric Home Care Manufacturers
  10. Dependability: We have been in business for over 45 years and will be around for many years to come. When you need us, we will be there.

Call our Hospital Bed

Specialist Today 800-733-1818

Big Boyz

Burke Bariatric

Drive Medical

Graham Field

Invacare

Medlift

Medline

Home

KING’S PRIDE 1000

KP1000

BED WIDTHS:

TWIN MODEL MODEL
38” X 80”KP38801

CONVERTIBLE MODEL
38/48” X 80” KP3848801

THREE QUARTER MODEL
48” X 80” KP48801

FULL MODEL
54” X 80” KP54801

QUEEN MODEL
60” X 80” KP60801

WEIGHT: FULL 1000 LBS. PATIENT CAPACITY

DECK HEIGHT: LOW POSITION 15 1/4”
HIGH POSITION 24 1/2”


Cardio Chair Position
Trendelenberg Position

FEATURES:

  • MULTIPLE POSITIONING
  • TRENDELENBERG
  • REVERSE TRENDELENBERG
  • CARDIO CHAIR
  • INDEPENDENT HEAD - KNEE GATCH FOR PERSONALIZED POSITIONING
  • FOOT SECTION DOES NOT PITCH DOWN BUT PLATEAUS TO REDUCE EDEMA OF LOWER EXTREMITIES


MATTRESS: (Included)

  • 6” FIRM COMFORT FOAM MATTRESS
  • CERTIFIED FOR TECHNICAL BULLETIN CAL TB 129
  • CERTIFIED FOR TECHNICAL BULLETIN CAL TB 603
  • Complies with the requirements of 16 CFR 1633
  • VENTREX TICKING (#1 LEADING HOSPITAL MATTRESS TICKING IN AMERICA)
  • ANTI-BACTERIAL
  • ANTI-FUNGAL
  • FLUID PROOF
  • FLAME RETARDANT
  • HAS EXTREMELY LOW VAPOR TRANSMISSION


OPTIONS:

  • SCALE/LOAD CELL/DIGITAL DISPLAY…………..MODEL: SC1000
  • SIDE RAILS/HEAVY DUTY………………………...MODEL: RA01920
  • BED MOUNTED TRAPEZE………………………...MODEL: TRKP1000
  • EXTENDED LENGTH/86”………………………… ..MODEL: KP100086
  • EMERGENCY BATTERY BACK-UP………………MODEL: EBU01
  • NURSE LOCK-OUT………………........................MODEL: NLO
  • ASSIST GRAB BAR..........................................MODEL: ASSTGRB
  • Side Rails/High/Heavy Duty...........................….MODEL: RA01920EX

PATIENT CONTROL:

  • 8 BUTTON CONTROL FOR ALL FUNCTIONS
  • LOW VOLTAGE
  • LOW ENERGY
  • HIGH IMPACT RESISTANT CASE

ELECTRONICS:

  • ELECTRONICS COMPLETELY ENCLOSED
  • FULLY GROUNDED, WITH HOSPITAL GRADE, 3 PRONG, HEAVY DUTY PLUG and CORD
  • ELECTRONICS and MOTORS UL LISTED
  • VOLTAGE 115V

    QUEEN’S PRIDE 600LM

EXTRA WIDE – HEAVY DUTY BED

MODEL: QUEEN’S PRIDE 600LM

SIZE MODEL

38” x 80” QP3880
48” x 80” QP4880
54” x 80” QP5480
60” X 80” QP6080

WEIGHT: FULL 750LBS PATIENT CAPACITY

DECK HEIGHT: LOW POSITION 14½”
HIGH POSITION 25”

FEATURES:
  • ALL ELECTRIC
  • STEEL PAN DECK…FOR PROPER MATTRESS SUPPORT
  • EASY TOUCH Hand CONTROL 12 VOLT
  • LARGE CAPACITY/EXTRA WIDE
  • ALL ELECTRONICS and MOTORS UL APPROVED
MATTRESS: (Included)
  • 6” HIGH DENSITY FOAM
  • FIRE BARRIER CERTIFIED FOR TECHNICAL BULLETIN CAL TB 129
  • FIRE BARRIER CERTIFIED FOR TECHNICAL BULLETIN CAL TB 603
  • Complies with the requirements of 16 CFR 1633
  • VENTEX TICKING (#1 LEADING HOSPITAL TICKING IN AMERICA)
  • ANTI-BACTERIAL
  • ANTI-FUNGAL
  • FLUID RESISTANT HAS EXTREMELY LOW VAPRO TRANSMISSION

MATTRESS COVER:

  • NYLON
  • WATERPROOF
  • ANTI-BACTERIAL
  • FLAME RETARDANT
  • ANTI-FUNGAL
OPTIONS:
  • SIDE RAILS/HEAVY DUTY………………………..MODEL: RA01920
  • BED MOUNTED TRAPEZE………………………..MODEL: TRQP38/TRQP48/TRQP54/TRQP60
  • SIDE RAILS/HIGH/HEAVY DUTY................MODEL: RA01920EX
  • SCALE/LOAD CELL/DIGITAL DISPLAY………....MODEL: SC600
  • EXTENDED LENGTH/86”……………………….….MODEL: QP3886/QP4886/QP5486/QP6086
  • EMERGENCY BATTERY BACK-UP……………..MODEL: EBU600
  • NURSE LOCK-OUT………………...................... MODEL: NLO600
  • ASSIST GRAB BAR......................................... MODEL: ASSTGRB
PATIENT CONTROL:
  • 8 BUTTON CONTROL FOR ALL FUNCTIONS
  • LOW VOLTAGE
  • LOW ENERGY
  • HIGH IMPACT RESISTANT CASE
ELECTRONICS:
  • ELECTRONICS COMPLETELY ENCLOSED
  • FULLY GROUNDED, WITH HOSPITAL GRADE, 3 PRONG, HEAVY DUTY PLUG and CORD
  • ELECTRONICS and MOTOR UL LISTED
  • VOLTAGE 115V

    QUEENand#8217;S PRIDE 600LM-CONVERTIBLE

    QP600
    CONVERT


BED WIDTHS: THREE QUARTER MODEL 48and#8221; X 80and#8221;

MODEL: QP3848

SIZE: 38and#8221;x 80and#8221; CONVERTS TO 48and#8221;x 80and#8221;

WEIGHT: FULL 750 LBS. PATIENT CAPACITY

DECK HEIGHT: LOW POSITION 14andfrac12;and#8221;
HIGH POSITION 25and#8221;

FEATURES:

  • ALL ELECTRIC
  • WEIGHT CAPACITY 750 LBS.
  • STEEL PAN DECKand#8230;FOR PROPER MATTRESS SUPPORT
  • EASY TOUCH Hand CONTROL 12 VOLTS
  • ALL ELECTRONICS and MOTORS UL APPROVED


MATTRESS: (INCLUDED)

  • 6and#8221; HIGH DENSITY FOAM
  • CERTIFIED FOR TECHNICAL BULLETIN CAL TB 129
  • CERTIFIED FOR TECHNICAL BULLETIN CAL TB 603
  • Complies with the requirements of 16 CFR 1633

MATTRESS COVER:

  • NYLON
  • WATERPROOF
  • ANTI-BACTERIAL
  • FLAME RETARDANT
  • ANTI-FUNGAL

OPTIONS:

  • SIDE RAILS/HEAVY DUTYand#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;.MODEL: RA01920
  • BED MOUNTED TRAPEZEand#8230;and#8230;and#8230;.and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;MODEL: TRQP3848
  • SCALE/LOAD CELL/DIGITAL DISPLAYand#8230;and#8230;and#8230;and#8230;and#8230;...MODEL: SC600
  • EXTENDED LENGTH/86and#8221;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;.MODEL: QP384886
  • EMERGENCY BATTERY BACK-UPand#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;.MODEL: EBU600
  • NURSE LOCK-OUTand#8230;and#8230;and#8230;and#8230;and#8230;and#8230;............................MODEL: NLO
  • ASSIST GRAB BAR...............................................MODEL: ASSTGRB

PATIENT CONTROL:

  • 6 BUTTON CONTROL FOR ALL FUNCTIONS
  • LOW VOLTAGE
  • LOW ENERGY
  • HIGH IMPACT RESISTANT CASE

ELECTRONICS:

  • ELECTRONICS COMPLETELY ENCLOSED
  • FULLY GROUNDED, WITH HOSPITAL GRADE, 3 PRONG, HEAVY DUTY PLUG and CORD
  • ELECTRONICS and MOTORS UL LISTED
  • VOLTAGE 115V

LOW BED 800

BED WIDTHS:

MODEL: LB3848
SIZE: 38andrdquo; X 80andrdquo; CONVERTS TO 48andrdquo; x 80andrdquo;

WEIGHT: FULL 1000 LBS. PATIENT CAPACITY

DECK HEIGHT: LOW POSITION 8 and#8221;
HIGH POSITION 24and#8221;

Cardio Chair Position
Trendelenberg Position

FEATURES:

  • MULTIPLE POSITIONING
  • TRENDELENBERG
  • REVERSE TRENDELENBERG
  • CARDIO CHAIR
  • INDEPENDENT HEAD - KNEE GATCH FOR PERSONALIZED POSITIONING
  • FOOT SECTION DOES NOT PITCH DOWN BUT PLATEAUS TO REDUCE EDEMA OF LOWER EXTREMITIES


MATTRESS: (Included)

  • 6and#8221; FIRM COMFORT FOAM MATTRESS
  • CERTIFIED FOR TECHNICAL BULLETIN CAL TB 129
  • CERTIFIED FOR TECHNICAL BULLETIN CAL TB 603
  • VENTREX TICKING (#1 LEADING HOSPITAL MATTRESS TICKING IN AMERICA)
  • ANTI-BACTERIAL
  • ANTI-FUNGAL
  • FLUID PROOF
  • FLAME RETARDANT
  • HAS EXTREMELY LOW VAPOR TRANSMISSION


OPTIONS:

  • SCALE/LOAD CELL/DIGITAL DISPLAYand#8230;and#8230;and#8230;and#8230;..MODEL: SCLB800
  • SIDE RAILS/HEAVY DUTYand#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;...MODEL: RA01920
  • BED MOUNTED TRAPEZEand#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;...MODEL: TRLB800
  • EXTENDED LENGTH/86and#8221;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;and#8230;.. MODEL: LB86
  • EMERGENCY BATTERY BACK-UPand#8230;and#8230;and#8230;and#8230;and#8230;and#8230;MODEL: EBULB
  • NURSE LOCK-OUTand#8230;and#8230;and#8230;and#8230;and#8230;and#8230;........................MODEL: NLO
  • ASSIST GRAB BAR..........................................MODEL: ASSTGRB
  • Side Rails/High/Heavy Dutyand#8230;............................RA01920EX

PATIENT CONTROL:

  • 8 BUTTON CONTROL FOR ALL FUNCTIONS
  • LOW VOLTAGE
  • LOW ENERGY
  • HIGH IMPACT RESISTANT CASE

ELECTRONICS:

  • ELECTRONICS COMPLETELY ENCLOSED
  • FULLY GROUNDED, WITH HOSPITAL GRADE, 3 PRONG, HEAVY DUTY PLUG and CORD
  • ELECTRONICS and MOTORS UL LISTED
  • VOLTAGE 115V

Burke, Inc. has been specializing in
since 1979.

As your authorized Burke Inc. dealer, we sell Burke Heavy Duty Bariatric Hospital Beds, Bariatric Transport Air Mattress System, Impulse Drive System, Accu-1000 Scale System, Bariatric Equipment including Bariatric Wheelchairs and Scooters.

Tri-Lift™TFIILogo

Enter/Exit at Foot of Bed
Center Section Seat Lift
1,000 lb. Capacity!

Tri-FlexIIBeige

Bariatric Seat Lift Bed

Seat Lift
True Chair Position
Walk Out of Foot of Bed
Expanding Patient Surface Width
Air Mattress (optional)
Impulse Drive System (optional)

Trendelenberg/Reverse Trendelenberg
Hi-Lo: 14” to 28”

trilift2

OPTIONS
-- Equipment Tree (with options)
-- Impulse Drive System
-- Integrated Scales
-- Air Mattress
-- Foam Mattress
-- Angle Indicators
-- Trapeze
-- Plexiglass Windowed Rails

Dimensions
--Platform: 37” Width x 80” Length
--------------48” Width x 80” Length
--Frame: 89” Long
------------40 3/4” Wide Caster to Caster

Class: Fully Electric: Modular Electronics
------37” Patient Surface Width for Transport
------48” Patient Surface Width for in room use
------UL 60601-1 / IEC 60601-2-38

Capacity: 1000 lbs.

Misc: Hospital Grade Plug
--Low Voltage/High Efficiency
--Heavy Duty 6” x 1 1/4” Steer - Lock Casters

Able to make small positioning corrections in the room with ease.

Moves bed down the hall at a walking pace or less at driver's discretion.

Will stop immediately yet gently by removing thumb/finger pressure off the joy stick.

Easily maneuvers in and out of doorways, elevators, turns, etc.

TRI-FLEX II™TFIILogo

MULTIPLE FEATURE, HIGH PERFORMANCE
BARIATRIC PLATFORM
1,000 lb. Capacity!

1,000 lb. Capacity - Static - Transfer
2 Patient Surface Widths in One Frame
3 Piece Interchangeable Width Mattress
“Fold - Roll” One Person Delivery System
Integrated Scale System Option
Exit/Enter at Foot of Bed Option
Expansion/retraction to 54” width
Fold Down Foot Rails
Plexiglas Windowed, Rotating Head Rails
Narrower Frame for improved doorway clearance

1 Button Trendelenberg functions
Improved Trapeze efficiency with enhanced patient access

New, Streamlined Dual Passage Assist
Impulse Drive System

Multiple Positions:
Trendelenberg / Reverse Trendelenberg
Tri-FlexIIBeige
Hi-Lo: 14” to 28”
Cardiac Chair Positioning
Independent Head - Knee Positioning
Integrated Scale System
Compact “Fold - Roll” 1 person delivery system

3 Widths in 1 Frame 37” to 48” or 54”
easy slide, expand/contract
3 - 4 Corner Trapeze Frame Setup
Impulse Drive System
Attendant Control
Angle Indicators
Battery Back-Up
CPR Release Mechanism
Easy Patient Egress at Foot or Side of
Bed

Dimensions
--Platform: 37” Width x 86” Length
--48” Width x 86” Length
--54” Width x 86” Length

Frame: 93 7/8” Long
--40 3/4” Wide Caster to Caster

Class: Fully Electric: Modular Electronics
--37” Patient Surface Width for Transport
--48” Patient Surface Width for in room use
--54” Patient Surface Width for in room use

UL 60601-1 / IEC 60601-2-38 and CE Mark
Capacity: 1000 lbs.

Misc: Hospital Grade Plug
--Low Voltage/High Efficiency
--(Low Power Consumption 1.6 amps)
--Heavy Duty 6” x 1 1/4” Steer - Lock Casters

tf2head

Durable Molded Reinforced Plastic Head and Foot Boards

tf2comp

Compact,
“Fold - Roll”,
1 Person Delivery
System

“Fold - Roll” Dimensions
----Width - 32”
----Height - 74 1/2”
----Length -46 1/2”
----(Hand Rail to Hand Rail)

tf2scaleEasiest to use Menu Driven Interface Scale

tf2rail

Patient Surface Width Panel Extends
To 48” or 54”

tf2loadcellLoad Cells - Specifically Positioned For The Most Accurate Bed Scale System


Easy Patient Egress
tf2egress

EASIER SAFER DOWNWARD TRANSFERS
The ultra low 14” deck height provides easier, safer into bed downward transfers for classic, short morbid obese patients.

The Tri-Flex II Deck is a “critical” 5” lower than the 19” deck of many bariatric beds, yet has the ability to adjust to a 28” deck height providing a safer, easier out of be downward transfer for the taller patient as well.

STREAMLINED
DUAL PASSAGE ASSIST OPTION

tf2assist
Help your patient In and Out of the Foot of the Bed with the Dual Passage Assist option. Designed specifically for the Burke Tri-Flex II, this unique system enhancement provides the option of exiting or entering the bed through the foot end, encouraging greater patient mobility.


3 or 4 Post Capability In One Trapeze System

tf2trap33 POST - 425 LBS. MAX CAP.
IMPROVED PATIENT ACCESS WITH 3 POST SYSTEM

tf2trap4

4 POST - 450 LBS. MAX CAP.

The Tri-Flex II Bariatric Bed provides smooth, safe transport of patients up to and including 1,000 lbs. Designed specifically for the maximum in stability and safety, providing dependable support to both patient and staff.


New Impulse Drive
Reduces Bariatric Care Injuries

Safer for staff-reduce need for dangerous transfers and expensive cumbersome lifts.

Save staff time
-no combing the facility for 4-6 nurses to move a 1,000 lb. patient and bed
through the facility or risk injury transferring to wheelchair.


Improve staff morale-Reducing the number of transfers means you reduce the threat
of career ending injuries and improve nursing staff morale in your bariatric unit.


Part of Emergency Evacuation Plan -Only one person is needed to move patient

ImpulseDriveMain Impulse Center-of-Bed Power Drive System is Best.

Provides superior maneuverability when compared to all Power Drives at end of bed.

50” Turning Radius, allowing (in room) tight positioning correction.

Impulse Bed Drive System is Safer for Staff, Saves Time and Simplifies Emergency Transport.

Burke Tri-Flex II andquot;Impulse Driveandquot; System
Safe and Easy Maneuverability through Variable Acceleration - Positioning.
Able to make small positioning corrections in the room with ease.
Moves bed down the hall at a walking pace or less at driver’s discretion.
Will stop immediately yet gently by removing thumb/finger pressure off the joy stick.
Easily maneuvers in and out of doorways, elevators, turns, etc.


TFIIPushHandlePush handles- Well positioned for optimum ease of use. Foam covered for a comfortable and safe grip. Affords less strain and effort for care givers while positioning or moving the bed. Also included with the Impulse Drive System.

TFIIAngleIndicator

Angle Indicators- Easy to read and self setting - shows the degree of angle of the head gatch for recording levels of patient comfort relating to upper body positioning.


Drive Medical

Drive Medical

Drive is... One of the fastest growing major manufacturers and distributors of durable medical equipment in the home healthcare, medical/surgical and rehabilitation markets in the United States. Our Mission... Is to manufacture and market world class products which focus on innovation, functionality and value to improve the quality of life and to promote independence for the individuals that use our products.

Full-Electric Bed

Full-Electric Bed 15005

Full-Electric Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • Quiet, smooth operation.
  • The easy-to-use hand pendant electrically controls the positioning of the upper body, knees, and overall height of the bed frame to provide maximum comfort and versatility for the patient or caregiver.
  • Side clips under angle iron store shaft when bed is unassembled.
  • Easy to set up.
  • Bed ships in two cartons.
  • Back and foot adjustment allow for an anatomically correct sleep surface.
  • Channel frame construction provides superior strength and reduced weight.
  • Reinforced frame resists twisting and bending.
  • Zinc coated spring deck.
  • Heavy duty, bed ends are attractive in any décor and easy to maintain.
  • Head and foot ends are interchangeable interchangeable with Invacare® and Sunrise®.
  • UL 73 pending.
  • CSA approved.
  • Manufactured in ISO9001 facility.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.

Semi-Electric Bed (Single Crank) 15004

Multi-Height Manual Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • Multi-height adjustable, by operating the hand cranks at the foot of the bed. Foot, head and overall bed height can be adjusted. Hand crank handles fold down to be concealed to prevent injury.
  • Side clips under angle iron store shaft when bed is unassembled.
  • Easy to set up.
  • Bed ships in two cartons.
  • Back and foot adjustment allow for an anatomically correct sleep surface.
  • Channel frame construction provides superior strength and reduced weight.
  • Reinforced frame resists twisting and bending.
  • Zinc coated spring deck.
  • Heavy duty, bed ends are attractive in any décor and easy to maintain.
  • Head and foot ends are interchangeable with Invacare® and Sunrise®.
  • CSA approved.
  • Manufactured in ISO9001 facility.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.

Multi-Height Manual Bed 15003

Multi-Height Manual Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • Multi-height adjustable, by operating the hand cranks at the foot of the bed. Foot, head and overall bed height can be adjusted. Hand crank handles fold down to be concealed to prevent injury.
  • Side clips under angle iron store shaft when bed is unassembled.
  • Easy to set up.
  • Bed ships in two cartons.
  • Back and foot adjustment allow for an anatomically correct sleep surface.
  • Channel frame construction provides superior strength and reduced weight.
  • Reinforced frame resists twisting and bending.
  • Zinc coated spring deck.
  • Heavy duty, bed ends are attractive in any décor and easy to maintain.
  • Head and foot ends are interchangeable with Invacare® and Sunrise®.
  • CSA approved.
  • Manufactured in ISO9001 facility.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.

Delta Ultra Light Plus, Semi-Electric Bed 15030

Ultra Light Plus, Semi-Electric Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • New universal style head and foot boards are interchangeable and feature high impact composite end panels.
  • Foot section weighs 50% less than conventional foot sections to make deliveries safe and easy.
  • Unique single motor and junction box assembly is completely self-contained to reduce noise.
  • The motor assembly can be easily installed and removed with patient in bed in seconds without tools.
  • The bed is easily assembled with only 5 components.
  • In the event of a power failure, a 9 volt battery, located in the motor, can lower the head and foot sections nine times. No crank needed.
  • New and improved hand pendant has large, easy to use controls.
  • Bed ships in two cartons.
  • Channel frame construction provides superior strength and reduced weight.
  • Zinc coated spring deck.
  • Extension kit available. (15030EXTKIT)
  • Bed weighs less than 150 lbs.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components

Delta Ultra Light, Full Electric Bed 15033

Ultra Light, Full Electric Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • New universal style head and foot boards are interchangeable and feature high impact composite end panels.
  • Height adjustment motor makes it easy for the patient or caregiver to raise or lower the height of the bed.
  • Height adjustment motor comes pre-installed on the foot section.
  • New crack-proof head and foot board panels.
  • The motor can be installed and removed with patient in the bed in seconds without tools.
  • In the event of a power failure, a 9 volt battery located in the motor, can lower the head and foot board sections 9 times.
  • New and improved hand pendant has large, easy to use controls.
  • Bed ships in two cartons.
  • Channel frame construction provides superior strength and reduced weight.
  • Zinc coated spring deck.
  • Bed weighs less than 160 lbs.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.

Full Electric LTC Bed 15801SD

Full Electric LTC Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • Designed for long term care use.
  • Separate bed height and head and foot section adjustment.
  • 3 motors provide quiet, smooth operation.
  • 80andquot; x 36andquot; spring deck surface.
  • Durable powder coated epoxy finish.
  • Bed rests on stabilizing legs in lowest position.
  • Equipped with locking casters
  • Sturdy, attractive head and foot boards.
  • UL Listed.
  • 450 lb. Weight Capacity.
  • Warranty: (Original purchaser) Lifetime on welds and frame, two years on electronics and 1 year on all parts and components.

Full Electric LTC Low Bed 15803SD

Full Electric LTC Low Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • Height adjustable sleep surface from 7.5andquot; to 17.5andquot;.
  • 3 motors provide quiet, smooth operation.
  • Separate bed height and head and foot section adjustment.
  • 80andquot; x 36andquot; spring deck surface.
  • Durable powder coated epoxy finish.
  • Sturdy, attractive head and foot boards.
  • UL Listed.
  • 450 lb. Weight Capacity.
  • Warranty: (Original purchaser) Lifetime on welds and frame, two years on electronics and 1 year on all parts and components.

Manual LTC Bed

15601SD

Manual LTC Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • Designed for long term care use.
  • Separate bed height and head and foot section adjustment.
  • 80andquot; x 36andquot; spring deck surface.
  • Durable, powder coated epoxy frame finish.
  • Bed rests on stabilizing legs in lowest position.
  • Equipped with locking casters.
  • Sturdy, attractive head and foot boards.
  • 450 lb. Weight Capacity.
  • Warranty: (Original purchaser) Lifetime on welds and frame, one year on all parts and components.

Spectrum Full Electric Long Term Care Bed

Spectrum Full Electric Long Term Care Bed

DOWNLOADABLE MATERIALS

Download SpecificationsDownload Catalog PDF

  • FEATURES.

  • Spectrum Full Electric Long Term Care Bed
    Item # Bed Bed Overall Overall Product Carton Weight
    Height Height Length Width Weight Shipping Limit
    Minimum Maximum 80andquot; Configuration Mattress Platform Weight
    SSB-730 7andquot; 30andquot; 86.25andquot; 35.5andquot; 199 lbs. 214 lbs. 500 lb

Delta Ultra Light Plus Full-Electric Low Bed 15235

Ultra Light Plus Full-Electric Low Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • 91/2andquot; to 20andquot; deck height.
  • Easy to set up.
  • 450 lb. weight capacity.
  • Height adjustment makes it easy for the patient or caregiver to raise or lower the height of the bed.
  • Height adjustable motor comes pre-installed on the foot section.
  • Durable and impact resistant, with washable end panels.
  • Caster easily moves from standard to low bed position.
  • The motor assembly can be easily installed and removed with patient in bed in seconds without tools.
  • In the event of a power failure, a 9 volt battery, located in the motor, can lower the head and foot sections nine times.
  • New and improved hand pendant has large, easy to use controls.
  • Bed ships in two cartons.
  • Channel frame construction provides superior strength and reduced weight.
  • Zinc coated spring deck.
  • When the bed is placed in the andquot;lowandquot; position, the side rails can not be lowered.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.

Ultra Light Plus Semi-Electric Low Bed 15230

Ultra Light Plus Semi-Electric Low Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • 9 1/2andquot; to 20andquot; deck height.
  • Easy to set up.
  • 450 lb. weight capacity.
  • Durable and impact resistant, with washable end panels.
  • Caster easily moves from standard to low bed position.
  • Foot section weighs 50% less than conventional foot sections to make deliveries safe and easy.
  • Unique single motor and junction box assembly is completely self-contained to reduce noise.
  • The motor assembly can be easily installed and removed with patient in bed in seconds without tools.
  • The bed is easily assembled with only 5 components.
  • In the event of a power failure, a 9 volt battery, located in the motor, can lower the head and foot sections nine times.
  • New and improved hand pendant has large, easy to use controls.
  • Bed ships in two cartons.
  • Channel frame construction provides superior strength and reduced weight.
  • Zinc coated spring deck.
  • Bed weighs less than 150 lbs.
  • When the bed is placed in the andquot;lowandquot; position, the side rails can not be lowered.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.

Full Electric Bariatric Bed 15300

Full Electric Bariatric Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • Quiet, smooth operation.
  • Heavy duty frame ensures strength and patient safety.
  • All steel construction.
  • Larger sleep surface than conventional bed.
  • Quiet, smooth operation.
  • Split pan design with removable bed ends is easy to set-up.
  • No tools necessary for set-up.
  • Hand control (included) provides for multiple bed positioning for patients.
  • Low air loss/alternating pressure mattress available.
  • Emergency manual crank included.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.


Full Electric Bariatric Bed 15302

Full Electric Bariatric Bed

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram

FEATURES

  • Quiet, smooth operation.
  • Heavy duty frame ensures strength and patient safety.
  • All steel construction.
  • Larger sleep surface than conventional bed.
  • Split pan design with removable bed ends is easy to set-up.
  • No tools necessary for set-up.
  • Hand control (included) provides for multiple bed positioning for patients.
  • Low air loss/alternating pressure mattress available.
  • Emergency manual crank included.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.

Full Electric Bariatric Bed 15303


Full Electric Bariatric Bed

Full Electric Bariatric Bed

FEATURES

  • Quiet, smooth operation.
  • Heavy duty frame ensures strength and patient safety.
  • All steel construction.
  • Larger sleep surface than conventional bed.
  • Split pan design with removable bed ends is easy to set-up.
  • No tools necessary for set-up.
  • Hand control (included) provides for multiple bed positioning for patients.
  • Low air loss/alternating pressure mattress available.
  • Emergency manual crank included.
  • Warranty: (Original purchaser) Lifetime on welds, 5 years on frame, 1 year on all other parts and components.

DOWNLOADABLE MATERIALS

Download Specifications Download Owners Manual Download Parts Diagram



GF Health Products, Inc.

Graham-Field

Headquartered in Atlanta, GA, GF Health Products, Inc. (andquot;Graham-Fieldandquot;) is one of the world's leading manufacturers and distributors of medical products in the health care industry, offering approximately 4,000 medical, rehabilitation, long-term care and homecare products.

They offer quality brands such as Everest - Jennings, wheelchair and seating products; Lumex , ambulatory, bath safety, pressure management and specialty seating products; Basic American, beds and institutional equipment; John Bunn , respiratory equipment; Labtron , diagnostic equipment; Grafco, a line of exam treatment products, and Lumiscope, diagnostics, all names you have come to trust for their quality and design.

Their innovative distribution programs and andquot;Single Sourceandquot; marketing strategy provide dedicated service and quality products to the health care market in a variety of market segments. Most importantly, our field and inside sales staff have undergone a rigorous training program to provide insight into reimbursement and managed care issues, detail product features and benefits and custom design programs to provide the highest level of professional service and customer satisfaction.

In addition to their headquarters in Atlanta, Graham-Field has distribution centers in Atlanta, GA; St. Louis, MO; East Rutherford, NJ; Los Angeles, CA; and Fond du Lac, WI. Our manufacturing facilities are located in various locations such as Fond du Lac, WI; and Central Falls, RI.

Introducing the new Graham Field Patriot Full-Electric Homecare Bed with a grid sleep surface!



Designed and engineered by the same team who develop the GF Long Term Care beds.
Sleep surface isMADE IN THE USA!

The single-motor design homecare bed is now available in a full-electric/low version. The Patriot Full-Electric Homecare Bed offers the same features as the Patriot Semi-Electric Homecare Bed with the additional feature of electric height adjustment. This makes it easier for caregivers to raise and lower the bed for patient care and linen changes. The electric height adjustment also enables the patient to easily position the bed for maximum comfort. The Full electric model can be adjusted to be a conventional height homecare bed OR a low bed for better inventory management!

  • Total assembled bed weighs only 178 pounds (bed and motor).
  • Powerful DC motor for effortless height adjustment.
  • Hi-Lo motor comes pre-installed on foot section for easy
  • set-up and disassembly.
  • All functions fully-integrated into convenient
  • handheld pendant.
  • Welded motor-guard protects motor and universal joint from damage during shipment and deliveries.
  • Available with Fiberboard Decorative Walnut Bed-ends or High-impact Plastic Bed-ends.
  • Designed to meet the requirements of applicable HCPCS codes.
  • Maximum patient weight 350 lbs.
  • 450 lb evenly distributed total weight capacity including patient, mattress, rails, and accessories.
  • Height Adjustment:
Casters in Low Position:
Min. 9.5andquot;, Max. 20andquot; (at deck level)
Casters in Standard Position:
Min. 13andquot;, Max. 23.5andquot; (at deck level)
  • Overall Bed Size: 87andquot; L x 36andquot; W.
  • Lift Range: Head - 60°, Knee - 30°.
  • No external pinch points!
  • Slots in frame to ensure proper rail placement.
  • Locking pins secure bed ends to sleep deck. Attached lanyards prevent loss while moving or storing.
  • Only homecare bed to offer a 4-inch extension kit that can extend either the head, foot, or both head and foot decking. Bed length will be 84andquot; with one kit, 88andquot; with 2 kits.
  • The only homecare bed to offer optional corner mattress retainers.

Grid Deck offers the following advantages:
  • Much stronger frame.
  • Better mattress support.
  • No spring sag or bottoming out with heavier patients.
  • Easier to clean.
  • No connecting links or springs to lose.

NOTE:

Half-Rail A (GF6650A-1 will not work on the Full-Electric Patriot homecare bed when the bed is used as a Low Bed. You would be unable to lower the rail completely.

Half-Rail B (GF6580A-1) can be used on the Full-Electric Patriot homecare bed when used at conventional height or as a low-bed.

Patriot Homecare Bed Semi-Electric



  • The motor unit and bed design provide the ultimate in quiet, smooth operation.
  • Complete welded steel frame construction.
  • The head and foot sections can be raised or lowered simultaneously or independently with one hand control.
  • During a power failure the motor unit can lower both the head and foot section with just a single standard 9 volt battery.
  • Assembles easily with just five components.
  • Designed to meet the requirements of applicable HCPCS codes.
  • Total bed weight assembled: 166 lb (bed and motor only).
  • Available with Fiberboard Decorative Walnut Bed-ends or
  • High-impact Plastic Bed-ends.
  • Maximum patient weight 350 lbs.
  • 450 lb evenly distributed total weight capacity including patient, mattress, rails, and accessories.
  • Bed Height: Min. 15andquot;, Max. 24andquot; (at deck level).
  • Lift Range: Head - 60°, Knee - 30°.
  • Overall Bed Size: 87andquot; L x 36andquot; W.
  • No external pinch points!
  • Slots in frame to ensure proper rail placement.
  • Locking pins secure bed ends to sleep deck. Attached lanyards prevent loss while moving or storing.
  • Only homecare bed to offer a 4-inch extension kit that can extend either the head, foot, or both head and foot decking. Bed length will be 84andquot; with one kit, 88andquot; with 2 kits.
  • The only homecare bed to offer optional corner mattress retainers .
Grid Deck offers the following advantages:
  • Much stronger frame.
  • Better mattress support.
  • No spring sag or bottoming out with heavier patients.
  • Easier to clean.
  • No connecting links or springs to lose.
Warranty:
  • Two year warranty for defects in workmanship and materials of techanical components, frame, and electronics.
  • During the warranty period, defective items will be repaired or replaced at manufacturerand#8217;s option. The warranty does not include any labor charges incurred in replacement part(s) installation or any associated freight or shipping charges to the manufacturer.
Bed shipped in three cartons:
1. Foot section and motor.
2. Head section and Hi/Lo rod.
3. Bed end set.

Skus

Please note that the pictures and descriptions on this page are representative of the product class. The stock codes below may be the product itself, or they may be associated stock codes related to the product being displayed. Please read the stock code description below to ensure you are ordering the correct item. Please call customer service if you have any questions regarding the correct stock code to choose.

Specifications

Additional Information

Product Documents

Product Sheet - Patriot Semi-Electric Homecare Bed

Manual - Patriot Homecare Bed

DMEPDAC Approval Letter US0208.pdf

Introducing the new Patriot Semi-Electric Homecare Bed with a grid sleep surface!
Designed and engineered by the same team who develop the GF Long Term Care beds.
Sleep surface and motors are MADE IN THE USA!

Bariatric Bed



ABL-B600 Full-Electric Bed Only 1 ea

  • Full-electric, three-function operation.
  • UL 73 and CAN/CSA C22.2 No. 68-92 approved.
  • Designed to meet the requirements of applicable HCPCS codes.
  • Split-frame with removable ends for easy transport.
  • Heavy-duty grid sleep deck.
  • Swing-down style trigger release rail (optional).
  • High-strength, steel-reinforced, truss frame.
  • Durable powder-coated finish.
  • Simple assembly: no special tools required.
  • Self-wrenching nut: assembled for easy part replacement.
  • Ball-screw bed ends.
  • Maximum patient weight is 600 lbs.
  • 700 lb evenly distributed total weight capacity including the patient, mattress, rails and accessories.
  • Bed height: low 17andquot; to high 27andquot;.
  • Overall bed dimensions: 46.5andquot; width (with rails) and 87andquot; length.
  • Sleeping surface dimensions: 42andquot; width and 80andquot; length.
  • Also available as a package with 650-1501-000 bariatric mattress and A7040 head half rails.

Warranty:
  • Two year warranty for defects in workmanship and materials of mechanical components, frame, and electronics.
  • During the warranty period, defective items will be repaired or replaced at manufacturer's option at no charge.

Skus

Please note that the pictures and descriptions on this page are representative of the product class. The stock codes below may be the product itself, or they may be associated stock codes related to the product being displayed. Please read the stock code description below to ensure you are ordering the correct item. Please call customer service if you have any questions regarding the correct stock code to choose.

Additional Information

Product Documents

Product Sheet - Bariatric Bed

User Manual - Bariatric Bed (Service Parts: Page 21)

DMEPDAC Approval Letter ABL-B600.pdf

Universal Homecare Bed




  • Frame is constructed of 10-gauge high-strength, low-alloy, cold-rolled steel for added strength.
  • The head spring section is reinforced on each side to prevent racking and bending.
  • All actuators use free wheeling (slip) clutches to eliminate the problems associated with unsynchronized components.
  • Self-wrenching nuts are used on all sleeping deck pivot points, making repairs easy to accomplish, and yielding and#8220;Good as Newand#8221; results.
  • Casters are 3andquot;: 2 locking and 2 non-locking.
  • All motors are 1/10 HP, 115 Volts/60 Hz, 1.6 amps and are protected from damage caused by misuse of the hand pendant via an override protection switch.
  • Vinyl-clad capping on bed ends is durable and mar-resistant.
  • All beds accommodate 36andquot; x 80andquot; mattresses.
  • Designed to meet the requirements of applicable HCPCS codes.
  • 450 lb maximum weight capacity.
  • Also available as a package with GF1500-180 80andquot; innerspring mattress and either GF6570A-1 full rails or GF6650A-1 head half rails.
  • UL 73 and CAN/CSA C22.2 No. 68-92 approved.

Warranty:
  • Two year warranty for defects in workmanship and materials of mechanical components, frame, and electronics.
  • During the warranty period, defective items will be repaired or replaced at manufacturer's option at no charge.

Skus

Please note that the pictures and descriptions on this page are representative of the product class. The stock codes below may be the product itself, or they may be associated stock codes related to the product being displayed. Please read the stock code description below to ensure you are ordering the correct item. Please call customer service if you have any questions regarding the correct stock code to choose.

Additional Information

Product Documents

Product Sheet - Universal Homecare Bed

User Manual - Universal Homecare Bed

Replacement Parts - Universal Homecare Bed

Intro Bed

Rigid low bed is designed to be safe and affordable.

  • Low height of 9.5andquot; to 20.25andquot;
  • 450 lb Dynamic Rated capacity
  • Meets FDA Entrapment guidelines
  • Locked when raised and rolls at low height
  • Locking Casters at all four corners
  • Back Mattress Deck articulates to approx 70 degrees
  • Knee Mattress Deck articulates to approx 30 degrees

The Intro and all Long Term Care Beds are sold a la carte; Head and Foot boards, Assist Devices, Mattresses and all options/accessories are sold separately.

Additional Information

Product Documents

The Intro.pdf

ALPHA II™

TheAlpha IIoffers a broad travel range – from 8.9andquot; low height for resident safety to 30andquot; high height for caregiver convenience. The low height allows residents to get in and out of bed easier while also reducing the risk of injury from a fall. With a low height, the need for restraints is less. The high height adjustment helps caregivers assist residents when transferring in and out of bed. Caregivers can also benefit from high height by aiding residents with eating, dressing and other daily activities. The highest position also provides caregivers with a safe working environment which helps reduce back injuries and strains.

Features:
  • Strong Supportive grid deckis superior in frame design and offers a “no-sag” mattress support surface
  • Patent pending designkeeps bed level and balanced at all times providing a more comfortable, restful sleep
  • 8.9 inch to 30 inch travel speedallows for bed positioning in as little as 22 seconds ...faster than most of the competition.
  • Straight verticaltravel takes up less room space
  • Quiet, Smooth operationby using four DC motors.
  • 360 degree mobilityatANYheight – can move from room to room atanyheight even thelowest.
  • Adjustable Leg lift systemcomes standard with Alpha II for improving comfort for residents with edema and poor leg circulation
  • Structured Baseprovides a reinforced, robust, base that is designed for support yet sufficient underbed clearance, ideal for using overbed tables and patient lifts
  • Wall Saveris adjustable for close positioning to walls and keeps your walls scratch free
  • Designed to supportthe use as a transport device, ideal for Sub-Acute and Rehab facility needs
Other features of theAlpha IIas a long-term care beds that address the needs of both caregivers and residents:
  • Resident controls allow for independence, comfort and security
  • Wallsaver Bumper Boards to protect walls
  • Corner Mattress Retainers
  • Easy-to-use controls with advanced staff control options available
  • Strong tubular head/foot board mounting can be used also as push bar
  • Compliant to industry regulatory bed standards
Highest Safety and Quality Standards
Built to conform to UL 60601-1 and IEC601-2-38, CAN/CSA C22.2 No. 601.1 the Liberty Bed offers the following ensuring the utmost resident and staff safety:

  • No pinch points within 200mm of bed perimeter
  • Rolling clearance of 20mm over thresholds
  • Splash-proof electronics
  • Load capacity and tip-stability testing

and For Infection Control…
Introducing SilverSolutions!

  • Superior, high efficacy that protects painted surfaces
  • Antimicrobial kills more than 99.9% of odor and stain causing bacteria
  • Lasts for the expected life of the bed
  • Non-allergenic and safe for the environment
  • High concentration of silver ions gives high efficacy
  • Requires no special handling
  • A cost-effective solution that is built-in to last

Accessories - Options
Extension Kit- Transform your bed to 84” improving inventory management of beds. Extension accommodates for a more broad range of resident heights.
Trapeze adapterallows for easy attachment of trapeze system to headboard with easy reach for residents.
Pendant Hand Control- Easy operation contoured Hand Control Pendant is shock-resistant, water-proof and durable. Holster conveniently secures to bedrails and assist devices for easy access. Backlit hand control with underbed light is optional.
Lok-n-Roll optionprovides a one-step locking system that is easily accessible even with low bed height
Deluxe castersfor enhanced mobility
Battery Back Upprovides the ability to perform bed functions in the event of power outage
Staff Control- Optional Embedded Staff Control allows staff to operate bed functions from the footboard. Staff can restrict access to the resident by locking out control from the resident pendant.
Half Length Assist Device and Assist Barprovide a sturdy and secure handhold to assist residents in and out of bed. Assist devices are removable without tools and meet FDA Entrapment Guidelines.

Basic AmericanAlpha II
Specifications
Additional Features Include:
– Electrostatic power coated antimicrobial bed surface provides longer lasting, durable finish
– Hospital Grade Grounded Plug is Standard
– U.S. Patents - US 7, 421, 748 1
– Multiple Patents Pending

Eze-Lokand#8482;



This bed represents a true engineering breakthrough, combining long term care needs with acute care features. The Eze-Lokand#8482; bed features a single pedal to secure the bed to the floor at any sleep surface height. The color-coded pedals show green for mobile and red for securely-locked.
and#8226; 12andquot; Low deck height. Maximum height is 24andquot;.
and#8226; Available in Manual Hi-Lo, Semi-Electric and Full-Electric.
and#8226; Available with spring, grid, orpan sleep deck.
and#8226; Durable powder-coated epoxy finish.
and#8226; 450 lb weight capacity.
and#8226; UL 2601-1 and CAN/CSA C22.2 No. 601-1-M90 approved.
and#8226; Available in 76andquot;, 80andquot;, or 84andquot; sleep deck lengths.
and#8226; Warranty:
1. Electronics: 2 Years
2. All other components: 15 Years.

The Eze Lok and all Long Term Care beds are sold a la carte; Head and Foot Boards, Assist Devices, mattresses and options/accessories are sold separately.


Additional Information

Product Documents

Eze-Lok.pdf

LIBERTY BED

Our newest addition from Basic American, The Liberty Bed provides you with the key features you want at a very affordable price point.
  • Strong supportive grid deckis superior in frame design and offers a “no-sag” mattress support surface. 450 lb. weight capacity.
  • Range of motion9.9 inch to 24.4 inch. With a standard 6” mattress, this positions the bed at an ideal height for the caregiver and for transfers.
  • One bed can be usedfor 76andquot; and 80andquot; lengths using the adjustable brackets to meet space limitations and improve inventory management. No extension kit is necessary.
  • Resident friendly, quiet, smooth operationkeeps bed level and balanced at all times using three DC motors.
  • 360 degree mobilityat ANY height – can move from room to room at any height, and move over thresholds at even the lowest position.
  • Mattress retaineris standard.
  • Reinforced, robust baseis designed for support yet provides sufficient underbed clearance, ideal for using overbed tables and patient lifts.
  • Easy assemblyrequires only a Phillips head screwdriver.
  • Four Locking Casterssecure the bed at any height.
  • New keyed Wall Saver is standard– easily moves over thresholds during transport, yet automatically falls back into place to protect your walls. Wallsaver adjusts easily when modifying bed from 76andquot; to 80andquot; and when using a trapeze.
  • Pendant Hand Control– Easy operation contoured Hand Control Pendant is shock-resistant, water-proof and durable. Holster conveniently secures to bedrails and assist devices for easy access.
Highest Safety and Quality Standards
Built to conform to UL 60601-1 and IEC601-2-38, CAN/CSA C22.2 No. 601.1 the Liberty Bed offers the following ensuring the utmost resident and staff safety:
  • No pinch points within 200mm of bed perimeter
  • Rolling clearance of 20mm over thresholds
  • Splash-proof electronics
  • Load capacity and tip-stability testing

and For Infection Control…
Introducing SilverSolutions!

  • Superior, high efficacy that protects painted surfaces
  • Antimicrobial kills more than 99.9% of odor and stain causing bacteria
  • Lasts for the expected life of the bed
  • Non-allergenic and safe for the environment
  • High concentration of silver ions gives high efficacy
  • Requires no special handling
  • A cost-effective solution that is built-in to last

Accessories - Options

Optional Trapeze Adapter and Trapezeattaches easily to headboard to position trapeze within easy reach of residents.
Optional Battery BackupProvides the ability to perform bed functions in the event of power outage.
Optional Half Length Assist Device and Assist BarHalf length assist device and assist bar provide a sturdy and secure handhold to assist residents in and out of bed. Assist devices are removable without tools and meet FDA Entrapment Guidelines.

Basic American Liberty Bed Specifications
Additional Features Include:
- Electrostatic powder-coated antimicrobial bed surface provides longer lasting, durable finish


Mattress Deck Length 76andquot;or 80andquot;
Mattress Deck Width 35andquot;
Overall Bed Length 85.5andquot; with bumper
Overall Bed Width 39.75andquot; with rails/assist devices
Maximum back angle 70°
Maximum knee angle 30°
Maximum height 24.4andquot;
Minimum height 9.9andquot;
Safe Workload (including resident, support surface, head/foot boards, and accessories)

Flex Bedand#8482;



and#8226;Hi-Lo Manual and Full-Electric available.
and#8226; Available in 76andquot; and 80andquot; sleep deck lengths.
and#8226; Low position 14.5andquot;, maximum height 26andquot;.
and#8226; Available with spring or pan sleep deck.
and#8226; Stabilizing legs standard.
and#8226; Durable powder-coated epoxy finish.
and#8226; 450 lb weight capacity.
and#8226; UL 2601-1 and CAN/CSA C22.2 No. 601-1-M90 approved.
and#8226; Warranty:
1. Electronics: 2 Years
2. All other components: 15 Years

The Flex and all Long Term Care beds are sold a la carte; Head and Foot Boards, Assist Devices, mattresses and options/accessories are sold separately.


Additional Information

Product Documents

Flex Bed.pdf

Matrix II™

The newMatrix IIis the latest addition to the innovative line of Basic American beds that offers a high quality bed with features to meet your resident long-term care needs while addressing pricing concerns. TheMatrix IIis designed with a superior grid deck sleep surface that provides the upmost security for your residents. With features such as adjustable hi-lo bed height adjustment and easy mobility, theMatrix IIprovides an ideal solution that meets both your resident and caregiver needs at an affordable price.

Features:
  • Patented designkeeps bed level and balanced at all times providing a more comfortable, restful sleep
  • Strong Grid deckis superior to old-fashioned spring link designs. Structural crossmembers offer a “nosag” mattress support surface that provides the ultimate support and is easy to clean and disinfect
  • Quiet, powerful and smooth operationby using only three DC motors – a peaceful operation and savings in maintenance cost versus traditional four or more motors
  • Smooth, rapid height adjustmentfrom a low 8.95andquot; to 25andquot; enhancing efficiency and reducing staff injury due to faster adjustment for proper resident care
  • Straight vertical traveltakes up less room space and keeps your walls scratch free
  • 360 degree mobility atANYheight– can move from room to room atanyheight, even thelowest
  • Structured Baseprovides a reinforced, robust, base that is designed for support yet offers sufficient underbed clearance, ideal for using overbed tables and patient lifts
  • Leg lift systemis optional feature used for improving comfort for residents with edema and poor leg circulation
  • Lok-n-Rolloption provides a one-step locking system that is easily accessible even with low bed height
Highest Safety and Quality Standards
Built to conform to UL 60601-1 and IEC601-2-38, CAN/CSA C22.2 No. 601.1 the Liberty Bed offers the following ensuring the utmost resident and staff safety:
  • No pinch points within 200mm of bed perimeter
  • Rolling clearance of 20mm over thresholds
  • Splash-proof electronics
  • Load capacity and tip-stability testing

and For Infection Control…
Introducing SilverSolutions!

  • Superior, high efficacy that protects painted surfaces
  • Antimicrobial kills more than 99.9% of odor and stain causing bacteria
  • Lasts for the expected life of the bed
  • Non-allergenic and safe for the environment
  • High concentration of silver ions gives high efficacy
  • Requires no special handling
  • A cost-effective solution that is built-in to last
Accessories - Options
Extension Kit- The 4andquot; extender is designed to extend the sleep surface an extra 4 inches. This allows the use of the 84andquot; mattress on an 80andquot;deck, or an 80andquot; mattress on a 76andquot; deck.
Trapeze - Trapeze Adapter- Trapeze is adjustable to accommodate residents’ reach. Adapter allows for easy attachment of trapeze system to headboard.
Pendant Hand Control- Easy operation contoured Hand Control Pendant is shock-resistant, water-proof and durable. Holster conveniently secures to bedrails and assist devices for easy access. Backlit hand control with underbed light is optional.
Half Length Assist Device and Assist Ba
r provide a sturdy and secure handhold to assist residents in and out of bed. Assist devices are removable without tools and meet FDA Entrapment Guidelines providing upmost security for residents.
Wall Saver Baseboard - Side Bumpers- Both Wall Saver Baseboard and Side Bumpers provide wall protection and eliminate the need for rollers.
Overbed Tables - Patient Lifts- Underbed clearance allows for easy use of overbed tables - patient lifts.


Basic AmericanMatrix II™Specifications
Additional Features Include:
– High Quality UL 60601, IEC601-2-38, CAN/CSA C22.2
No. 601.1 compliance meets the highest global safety standards for electrical medical equipment
– Electrostatic powder-coated antimicrobial bed surface provides a longer-lasting, durable finish
– Grounded – Standard Hospital Grade
– Comes standard with Corner Mattress Retainers
– U.S. Patents - US 7,421,748 1
– Multiple Patents Pending

Növus™

TheNövusoffers you many of the features of a top-of-the-line full-electric bed, at an economical value, for your long term care needs. Affordability, safety features, durability, and innovative design are all included with theNövus, maintaining the level of quality bed you’ve come to expect from Basic American. The independent and simultaneous operation of the head, knee and hi-lo functions provides a multitude of bed positions for the ultimate in resident comfort and care.

Features:

  • Patent-pendingdesign keeps bed level and balanced at all times, providing a more comfortable, restful sleep
  • Quiet, powerful, smooth operationby using only three DC motors – a smooth operation and savings in maintenance cost versus the traditional use of four or more motors
  • Smooth, rapid height adjustmentfrom a low 8.95'' to high 30andquot; improves efficiency and reduces the risk of staff injury due to faster height adjustment for proper resident care
  • Strong Grid deckis superior to old-fashioned spring link designs. Structural crossmembers offer a “no-sag” mattress support surface
  • Straight verticaltravel takes up less room space
  • 360 degree mobility atANYheight– can move from room to room atanyheight, even thelowest
  • Structured Baseprovides a reinforced, robust base that is designed for support, yet offers sufficient underbed clearance, ideal for using overbed tables and patient lifts
  • Adjustable Leg lift systemcomes standard withNövus,improving comfort for residents afflicted by edema and poor leg circulation
  • Standard Caster Lock Systemor Lok-n-Roll option provides a one-step locking system that is easily accessible even with low bed height
Highest Safety and Quality Standards
Built to conform to UL 60601-1 and IEC601-2-38, CAN/CSA C22.2 No. 601.1 the Liberty Bed offers the following ensuring the utmost resident and staff safety:
  • No pinch points within 200mm of bed perimeter
  • Rolling clearance of 20mm over thresholds
  • Splash-proof electronics
  • Load capacity and tip-stability testing

and For Infection Control…
Introducing SilverSolutions!

  • Superior, high efficacy that protects painted surfaces
  • Antimicrobial kills more than 99.9% of odor and stain causing bacteria
  • Lasts for the expected life of the bed
  • Non-allergenic and safe for the environment
  • High concentration of silver ions gives high efficacy
  • Requires no special handling
  • A cost-effective solution that is built-in to last

Accessories - Options
Extension Kit- The 4andquot; extender is designed to extend the sleep surface an extra 4 inches. This allows the use of the 84andquot; mattress on an 80andquot;deck, or an 80andquot; mattress on a 76andquot; deck.
Trapeze - Trapeze Adapter- Trapeze is adjustable to accommodate residents’ reach. Adapter allows for easy attachment of trapeze system to headboard.
Pendant Hand Control- Easy operation contoured Hand Control Pendant is shock-resistant, water-proof and durable. Holster conveniently secures to bedrails and assist devices for easy access. Backlit hand control with underbed light is optional.
Half Length Assist Device and Assist Ba
r provide a sturdy and secure handhold to assist residents in and out of bed. Assist devices are removable without tools and meet FDA Entrapment Guidelines providing upmost security for residents.
Wall Saver Baseboard - Side Bumpers- Both Wall Saver Baseboard and Side Bumpers provide wall protection and eliminate the need for rollers.
Overbed Tables - Patient Lifts- Underbed clearance allows for easy use of overbed tables - patient lifts.


Basic AmericanNövus™
Specifications
Additional Features Include:
High Quality UL 60601, IEC601-2-38, CAN/CSA C22.2
No. 601.1 compliance meets the highest global safety standards for electrical medical equipment
– Electrostatic powder-coated antimicrobial bed surface provides a longer-lasting, durable finish
– Hospital Grade Grounded Plug is Standard
– Comes standard with Corner Mattress Retainers
– U.S. Patents - US 7,421,748 1
– Multiple Patents Pending

Zenith Z3™

heZenith Z3, developed with both resident and caregiver in mind, is raising the bar in Long Term Care beds. While incorporating many of the same top quality features you’ve come to expect with the Zenith beds, the newZenith Z3now offers unprecedented, advanced positioning speed that is faster than most of the competition - thus saving time and reducing staff occupational injury when adjusting beds for resident care. With its superior design and quiet operation, the newZenith Z3provides speed, safety, and the solution from a name you’ve come to trust.

Features:

  • Patent pending Dual Tie-Bardesign keeps bed level and balanced at all times providing a more comfortable, restful sleep
  • Unprecedented positioning speedallows for bed positioning from a low 7.9andquot; to 30andquot; in as little as 26 seconds
  • Strong Supportive grid deckis superior in frame design and offers a “no-sag” mattress support surface
  • Virtually 100%vertical movement allows bed to take up less room space
  • Industry leading Z-lok foot caster basewith easy access one step red-green pedal locking system to maximize security, mobility, and when locked can be seen from a distance
  • 360 Degree Mobility atANYheight– can move from room to room atanyheight even thelowest
  • Quiet, Smooth operationby using 4 DC motors
  • Adjustable Leg lift systemcomes standard with Z3 for improving comfort for residents with edema and poor leg circulation
  • Wall Saver Bumpercomes standard and eliminates the need for rollers that damage walls
  • Customized headboards and footboardsare available in a variety of styles and finishes to compliment any room décor
Highest Safety and Quality Standards
Built to conform to UL 60601-1 and IEC601-2-38, CAN/CSA C22.2 No. 601.1 the Liberty Bed offers the following ensuring the utmost resident and staff safety:
  • No pinch points within 200mm of bed perimeter
  • Rolling clearance of 20mm over thresholds
  • Splash-proof electronics
  • Load capacity and tip-stability testing

and For Infection Control…
Introducing SilverSolutions!

  • Superior, high efficacy that protects painted surfaces
  • Antimicrobial kills more than 99.9% of odor and stain causing bacteria
  • Lasts for the expected life of the bed
  • Non-allergenic and safe for the environment
  • High concentration of silver ions gives high efficacy
  • Requires no special handling
  • A cost-effective solution that is built-in to last

Accessories - Options
Zfast- WithZFast, average speed for positioning is 1andquot;/second at full 500 lb capacity.ZFastcan reduce the chance for staff injury by reducing any bending and physical strain and improve resident care.
Extension Kit- Transform your bed to 84” improving inventory management of beds. Extension accommodates for a more broad range of resident heights.
Trapeze adapterallows for easy attachment of trapeze system to headboard with easy reach for residents.
Pendant Hand Control- Easy operation contoured Hand Control Pendant is shock-resistant, water-proof and durable. Holster conveniently secures to bedrails and assist devices for easy access. Backlit hand control with underbed light is optional.
Staff Control- Optional Embedded Staff Control allows staff to operate bed functions from the footboard. Staff can restrict access to the resident by locking out control from the resident pendant.
Half Length Assist Device and Assist Barprovide a sturdy and secure handhold to assist residents in and out of bed. Assist devices are removable without tools and meet FDA Entrapment Guidelines.

Full Electric Home Care Bed
IVC Full-Electric Home Care Bed

Product ID: 5410IVC
HCPCS Code: E0266**
HMESA CODE: 10-10-02-04

Invacare introduces the next generation Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle. The new IVC bed components such as the Universal Bed End, headspring, and footspring are interchangeable with your existing Invacare bed fleet, so you can now upgrade your fleet with these enhancements. These new features are designed to be easier to deliver, set-up, clean, and maintain.

  • High Impact Bed End Panels are more durable, impact and scratch resistant, and washable for easy cleaning
  • Universal Bed End can be used as either headboard or footboard on any Invacare Bed with the use of the IVC drive shaft with silver decal
  • DC low voltage, compact motor system is faster, quieter, and lighter than the old system and the IP66 rated waterproof enclosures allow the entire system to be washable with standard water pressure (Power washing is not recommended)
  • Extended maintenance schedule - every 3 years or with every new user
  • Patent pending. UL 73, UL 962, and UL 2601 approved
  • Bed Height: 15andquot; min. - 23andquot; max. (Measurement from floor to bed deck.)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/electrical: 2 years

    Full Electric Home Care Bed - Low
    Full-Electric Low Bed

    Product ID: 5410LOW
    HCPCS Code: E0266**
    HMESA CODE: 10-10-02-04

  • Invacare brings the safety and convenience of a low bed into the Home Care Bed Series with the new IVC Full-Electric Low Bed. The split-spring design incorporated into the standard low bed profile combines the easy, one-person delivery of an Invacare bed with the benefits of a low bed, where rails are not desirable or appropriate, but injuries from falling out of bed are still a concern. The IVC Low Bed ends are fully compatible with existing Invacare full-electric bed frame inventories and the IVC drive shaft, simplifying inventory management for providers and long-term care facilities.


  • 9.5andquot; minimum floor-to-bed deck height
  • 20andquot; maximum floor-to-bed deck height
  • UL962 and CSA approved
  • 450-pound total weight capacity
  • Universal low bed ends are durable, impact resistant and washable for easy cleaning

  • Bed Height: 9.5andquot; min. - 20andquot; max. (measured from floor to bed deck)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/Electrical: 2 Years

    Semi-Electric Home Care Bed
    Semi-Electric Home Care Bed

    Product ID: 5310IVC
    HCPCS Code: E0261**
    HMESA CODE: 10-10-02-04

    Invacare introduces the next generation Home Care Bed, offering a number of innovations that translate into long-term savings over the product lifecycle. The new IVC bed components such as the Universal Bed End, headspring, and footspring are interchangeable with your existing Invacare bed fleet, so you can now upgrade your fleet with these enhancements. These new features are designed to be easier to deliver, set-up, clean, and maintain

  • High-Impact Bed End Panels are more durable, scratch-resistant, and washable for easy cleaning
  • Universal Bed End can be used as either headboard or footboard on any Invacare Bed with the use of the IVC drive shaft with silver decal
  • DC low-voltage, compact motor system is faster, quieter, and lighter than the old system and the IP66 rated waterproof enclosures allow the entire system to be washable with standard water pressure (Power washing is not recommended)
  • Extended maintenance schedule - every 3 years or with every new user
  • Patent pending. UL 73, UL 962, and UL 2601 approved
  • Bed Height: 15andquot; min. - 23andquot; max. (Measurement from floor to bed deck.)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years
    Mechanical/Electrical: 2 years

    Value Care Semi-Electric Bed
    Value Care Semi-Electric Bed

    Product ID: VC5310
    HCPCS Code: E0295**
    HMESA CODE: 10-10-02-03

    The Value Care Semi-Electric Bed is now available, in stock, and ready to ship. Featuring the popular universal bed ends with the Invacare deck design, the Value Care bed utilizes a single motor design making the bed lightweight and easy to assemble. It also features a 9V battery backup providing low cost protection from power outages. The advanced pendant design allows the head and knee sections to move either simultaneously or independently at the push of a button.

  • Single motor design makes the bed lightweight and easy to assemble.
  • 9V battery backup provides convenient low cost protection in case of power outages.
  • Advanced pendant design allows head and knee sections to operate simulataneously or independently.
  • Universal bed ends are high impact and resist impacts and scratches.
  • Bed Height: 15andquot; to 23andquot;
    Dimensions: Overall 36andquot; W x 88andquot; L
    Sleep Surface: 36andquot; W x 80andquot; L
    Product Weight: VC5000, Head Spring, 50 lbs
    VC5890, Foot Spring, 65 lbs
    5301IVC, Universal Bed Ends, 53 lbs
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: 2-year limited warranty

    Full Electric Bed Package with Innerspring Mattress and Half Rails
    Bed Package - 5410IVC,5185,6630

    Product ID: BED9-1633
    HCPCS Code: E0265**
    HMESA CODE: 10-10-02-04

    Invacare introduces the next generation Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle.

  • 5410IVC Full-Electric Bed
  • 5185 Deluxe Innerspring Mattress
  • 6630 Side Rails
  • 5185 Mattress meets fire regulation code 16 CFR 1633 and 16 CFR 1632
  • Bed Height: 15andquot; min. - 23andquot; max. (Measurement from floor to bed deck.)
    Dimensions: Overall: 36andquot;W x 88andquot;L

    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/electrical: 2 years

    Semi-Electric Bed Package - 5310IVC, 6630, 5185
    Bed Package - 5310IVC, 5185, 6630

    Product ID: BED10-1633
    HCPCS Code: E0260**
    HMESA CODE: 10-10-02-03

    Invacare introduces the next generation Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle.

  • 5310IVC Semi-Electric Bed
  • 5185 Deluxe Innerspring Mattress
  • 6630 Half-Length Side Rails
  • 5185 mattress meets Fire Regulation Standards 16 CFR 1633 and 16 CFR 1632
  • Bed Height: 15andquot; min. - 20andquot; max. (measured from floor to bed deck)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/Electrical: 2 Years

    Semi-Electric Bed Package - 5310IVC, 6629, 5180
    Bed Package - 5310IVC, 5180, 6629

    Product ID: BED32-1633
    HCPCS Code: E0260**
    HMESA CODE: 10-10-02-03

    Invacare introduces the next generation Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle.

  • 5310IVC Semi-Electric Bed
  • New 5180 Home Care Foam Mattress
  • 6629 Side Rails
  • Bed Height: 9.5andquot; min. - 20andquot; max. (measured from floor to bed deck)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/Electrical: 2 Years

    Full Electric Bed Package with Solace Prevention Foam Mattress
    5410IVC, 6630, SPS0080

    Product ID: BED23-1633
    HCPCS Code: E0265**

    Home Care Bed. The Invacare IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle.

  • 5410IVC Semi Electric Bed
  • SPS0080 Solace Prevention Foam Mattress
  • 6630 Half-Length Bed Rail
  • Bed Height: 15andquot; min. - 23andquot; max. (Measurement from floor to bed deck.)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/electrical: 2 years

    Full Electric Bed Package - 5410IVC, 6630, 5180
    Bed Package - 5410IVC,5080,6630

    Product ID: BED37-1633
    HCPCS Code: E0265**
    HMESA CODE: 10-10-02-04

    Invacare introduces the next generation Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle.

  • 5410IVC Full-Electric Bed
  • New 5180 Home Care Foam Mattress
  • 6630 Side Rails
  • Bed Height: 15andquot; min. - 23andquot; max. (Measurement from floor to bed deck.)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/electrical: 2 years

    Semi-electric Bed Package - 5310IVC, 6630, 5180
    Bed Package - 5310IVC,5180,6630

    Product ID: BED36-1633
    HCPCS Code: E0260**
    HMESA CODE: 10-10-02-03

    Invacare introduces the next generation Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle

  • 5310IVC Semi-Electric Bed
  • NEW 5180 Home Care Foam Mattress
  • 6630 Half-Length Side Rails
  • Bed Height: 15andquot; min. - 23andquot; max. (Measurement from floor to bed deck.)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/electrical: 2 years

    Low Bed Package - 5410LOW, 6632, 5185

    Bed Package - 5410LOW, 5185, 6632

    Product ID: BED38LOW-1633
    HCPCS Code: E0265**
    HMESA CODE: 10-10-02-04

    Invacare introduces the next generation Home Care Low Bed which offers a number of innovations that translate into savings over the product lifecycle.

  • 5410LOW Full-Electric Low Bed
  • 5185 Innerspring Mattress
  • 6632 Assist Rails
  • The 5185 mattress meets Fire Regulation Codes 16 CFR 1633 and 16 CFR 1632
  • Back Height: 9.5andquot; min. - 20andquot; max. (measured from floor to bed deck)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/Electrical: 2 Years

    Value Care Bed Package - VC5310, 6629 5185
    Value Care Semi-Electric Bed Package

    Product ID: VCPKGIVC-1633
    HCPCS Code: E0260**
    HMESA CODE: 10-10-02-03

    This Value Care Semi-Electric Bed Package includes the VC5310 semi-electric bed, the 6629 full-length bed rail and the 5185 innerspring mattress. 5185 mattress meets 16 CFR 1633 and 16 CFR 1632 Fire Regulation Standards

  • Single Motor Design makes the bed lightweight and easy to assemble.
  • 9V Battery Backup provides convenient low cost protection in case of power outages.
  • Advanced Pendant Design allows head and knee sections to operate simulataneously or independently.
  • Universal Bed Ends are high impact and resist impacts and scratches. Advanced Pendant Design allows head and knee sections to operate simulataneously or independently.
  • Bed Height: 15andquot; to 23andquot;
    Dimensions: Overall 36andquot; W x 88andquot; L

    Sleep Surface: Overall 36andquot; W x 88andquot; L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: 2-year material, workmanship and electrical

    Value Care Bed Package - VC5310, 6630, 5185
    Value Care Semi-Electric Bed Package

    Product ID: VCPKGIVC2-1633
    HCPCS Code: E0260**
    HMESA CODE: 10-10-02-03

    This Value Care Semi-Electric Bed Package includes the VC5310 semi-electric bed, the 6630 half length bed rail and the 5185 innerspring mattress.

  • Single Motor Design makes the bed lightweight and easy to assemble.
  • 9V Battery Backup provides convenient low cost protection in case of power outages.
  • Advanced Pendant Design allows head and knee sections to operate simulataneously or independently.
  • Universal Bed Ends are high impact and resist impacts and scratches.
  • Bed Height: 15andquot; to 23andquot;
    Dimensions: Overall 36andquot; W x 88andquot; L
    Sleep Surface: 36andquot; W x 80andquot; L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: 2-year material, workmanship and electrical

    Semi Electric Bed Package with Solace Prevention Foam Mattress
    5310IVC, 6630, SPS1080

    Product ID: BED43-1633
    HCPCS Code: E0260**

    Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle.

  • 5310IVC Semi Electric Bed
  • SPS1080 Solace Prevention Foam Mattress
  • 6630 Half-Length Bed Rail
  • Bed Height: 15andquot; min. - 23andquot; max. (Measurement from floor to bed deck.)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/electrical: 2 years

    Full Electric Bed Package with Innerspring Mattress and Full-Length Rails

    Bed Package - 5410IVC, 5185, 6629

    Product ID: BED2-1633
    HCPCS Code: E0265**
    HMESA CODE: 10-10-02-04

    Invacare introduces the next generation Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle.

  • 5185 Deluxe Innerspring Mattress
  • 5410IVC Full-Electric Bed
  • 6629 Full-Length Side Rails
  • Meets Fire Regulation Code 16 CFR 1633 and 16 CFR 1632
  • Bed Height: 15andquot; min. - 23andquot; max. (Measurement from floor to bed deck.)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/electrical: 2 years

    Full Electric Bed Package - 5410IVC, 6629, 5180

    Bed Package - 5410IVC, 5180, 6629

    Product ID: BED33-1633
    HCPCS Code: E0265**
    HMESA CODE: 10-10-02-04

    Invacare introduces the next generation Home Care Bed. Invacare's IVC Home Care Bed offers a number of innovations that translate into long-term savings over the product lifecycle.

  • 5410IVC Full-Electric Bed
  • New 5180 Foam Home Care mattress
  • Bed Height: 15andquot; min. - 20andquot; max. (measured from floor to bed deck)
    Dimensions: Overall: 36andquot;W x 88andquot;L
    Sleep Surface: 36andquot;W x 80andquot;L
    Product Weight Capacity: 350 lbs. patient weight
    450 lbs. inclusive of all accessories
    Warranty: All Welds: 5 years Mechanical/Electrical: 2 Years

    Bariatric Bed - 750 Lbs
    Bariatric Bed - 750-Pound

    Product ID: BAR750

    The BAR750 bariatric bed is a heavy-duty full-eletric bed frame capable of supporting up to 750 pounds. With the end user in mind, this bed expands from 39andquot; wide to a full 48andquot; and from 80andquot; in length to 88andquot;. Four ultra-quiet DC actuators easily reposition the head and foot sections, as well as the bed height. and, for the ultimate in safety, the bed comes standard with a battery backup.

  • Heavy-duty frame design ensures added strength for client support
  • 700 lbs. patient weight capacity. 750 lbs. total weight capacity
  • Integrated battery backup, bed ends and half rails standard
  • Split-spring design eases delivery and setup
  • Quiet, smooth operatio
  • Bed Height: 15.5andquot; - 29.5andquot;
    Sleep Surface: 80andquot; to 88andquot;L x 39andquot; to 42andquot; to 48andquot;W
    Overall Length: 88andquot;
    Overall Width: 48andquot;
    Warranty: Welds: 5 years
    Mechanical / Electrical: 3 year
    Shipping Product Weight: 465 lbs.
    Dimensions: 56andquot; x 44andquot; x 41andquot;

    Bariatric Bed Package - BAR600IVC, BARMATT42, BAR6640IVC
    Bariatric Bed Package - BAR600IVC, BARMATT42, BAR6640IVC

    Product ID: BARPKGIVC-1633


    The Bariatric Bed is a heavy-duty full-electric bed frame designed for bariatric individuals, capable of supporting up to 600 pounds. The bed frame extends to the edges of the bed deck for better support. Using the hand pendant, the client or caregiver is able to change the positioning of the head and foot sections, as well as the bed height. and, even though this is a substantial bed, setup within the home is easy.


  • Heavy-Duty frame design ensures added strength for client support
  • No special tools necessary for in-home setup
  • 600-pound client weight capacity
  • Heavy-duty bed sleep surface is 17% larger than standard beds to ensure comfortable positioning
  • Split-spring design with removable bed ends for ease in setup


    Product Weight Capacity: 600 pounds
    Bed Height: Floor to Bed Deck: min. 14andquot; - max. 22andquot;
    Dimensions: Sleep Surface: 80andquot;L x 42andquot;W
    Warranty: Mechanical / Electrical: 1 Year Frame / Structure: 5 Years All Welds: 5 Years
  • 750-Pound Bariatric Bed Package
    750 lbs Bariatric Bed Package - BAR750, BARMATT39

    Product ID: BARPKG750-1633


    The BARPKG750 Bariatric Bed Package includes the BAR750 and BARMATT39, which offers a heavy-duty full-electic bed and mattress with a 675-pound patient weight capacity.



  • Split-spring design for easy home delivery and set-up
  • 675 lbs patient weight capacity 750 lbs total weight capacity
  • Integrated battery backup, bed ends, and half rails standard
  • Two locking casters on the head section and two steering lock casters on the foot section
  • Two high-low motors, one on the head section and one on the foot section


    Bed Height: min. 15.5andquot; - max. 29.5andquot;
    Sleep Surface: Length - 80andquot; - 88andquot;
    Width - 39andquot;, 42andquot; - 48andquot;
    Shipping Product Weight: 465 lbs.
    Warranty: Frame / Structure: 5 years
    Mechanical / electrical: 1 year
  • 600 lb. Bariatric Bed
    Bariatric Bed

    Product ID: BAR600IVC


    The Bariatric Bed is a heavy-duty full-electric bed frame designed for bariatric individuals, weighing up to 600 pounds. The bed frame extends to the edges of the bed deck for better support. Using the hand pendant, the client or caregiver is able to change the positioning of the head and foot sections, as well as the bed height. and, even though this is a substantial bed, setup in the home is easy. (UL962)



  • Split-spring design with removable, universal bed ends for easy set-up.
  • Heavy-duty frame design ensures added strength for client support.
  • Bed sleep surface is 17% larger to ensure comfortable positioning.
  • No special tools necessary for in-home setup.
  • Quiet, smooth operation


    Bed Height: Minimum: 14andquot; - Maximum: 22andquot;
    Sleep Surface: 80andquot;L x 42andquot;W
    Overall Length: 88andquot;
    Overall Width: 42andquot;
    Warranty: All Welds: 5 years
    Mechanical/Structural:1 year
    Electrical: 1 year
    Product Weight Capacity: 600 lb. patient weight capacity
    650 lb. total weight capacity including all accessories.


  • Medlift Flex a Bed

    Medical FlexABed

    Medical FlexABed

    Medical FlexABed

    The Flex-A-Bed Dual King - Our most popular modelThe Flex-A-Bed Dual King - Our most popular model


    Now for the first really new advances in3 motor, fully electric hospital adjustable bed. The incredible full and queensizeFlex-A-Bed. Sleep easier in unbelievable comfort. Elevate your back and your legs at the simple touch of your finger. Elevate the entire bed up and down at the simple touch of your finger.

    Why do you need the third motor to make an adjustable bed a 3 motor, fully electric adjustable bed? Some people are very short, and would like the bed a little lower to get in and out. Some people have to transfer into a wheelchair, and would like the bed at the same height. Some people are tall, and want the thigh to be above the kneecap to make getting out of bed easier. Some people are under nurses care, and need the bed to be elevated to help the nurse move the patient.

    What is the difference between a Flex-A-Bed and a Hospital Bed? A Flex-A-Bed looks like a beautiful, normal bed - not an ugly hospital bed. You will Love your Flex-A-Bed.

    Flex-A-Bed3 Motor Hospital Bed

    3-motor electric bed full size

    Electric Adjustable Bed flex-a-bed

    Entire Bed goes up and down.

    3 Motor Hospital Bed

    Optional Side Rails

    Hospital Bed flexabed fully electric remoteControl

    Head Up and Head Down; Foot Up and Foot Down; Total Bed Up and Down

    Flex A Bed Adjustable 3 motor Hospital Bedflexabed electric 3 motor adjustable bed Electric Bed 3-motor queensize flexabed

    Ordinary bed require you to twist and turn, trying to get comfortable. ButFlex-A-Bedadjusts to fit your body exactly. This precise support takes the strain off back muscles. So you'll instantly feel the

    comfort that bring on a restful, relaxing sleep.

    3 Motor Hospital Bed Flexabed

    Flex-A-Bed Queen Size Fully Electric BedFlex-A-Bed Full Size 3 Motor Hospital BedRegular Size Flex-A-Bed

    Flex-A-Bed3-motor fully electric full (double and regular size) and queen electric adjustable hospital bed. A standard hospital bed has two motors that can be operated separately or together. This means that you have unlimited control over the position settings of the bed.

    The hand control allows you to select any position you like, then change positions again at the touch of a button:

    1. The lightweight control is simple and#65533; much easier to use than a VCR or TV remote
    2. It operates the head and foot motors as well as the optional vibrator unit
    3. You can even choose between single massage or dual massage for your Flex-A-Bed.


    • Flex-A-Bed 3 Motor Adjustable Bed

    • Full Size Hospital Bed

    • Regular Size Fully Electric Adjustable Bed

    • Queen Size 3 Motor Adjustable Bed

    • Double Size Hospital Bed

    • Flex-A Bed-Single Side Rails

    • 3 Motor Hospital Bed

    Flex-A-Bed / Flexabed / 3-Motor / Hi-Lo / High-Low Searching Words:

    heavy duty lightweight portable store company inexpensive ratings bariatrics find discount pricing rating power motorized powered automatic electronic company electrical home page pics info pictures video hospital bariatric electrically used lifting American care centers clinic healthcare clinics center equipment supplies rehab services resources sale big insurance mobility obesity lifters www com cheap sale benefits mobility medical elderly senior my about best quality prices buy co cost usa discount online store dealer manufacturer factory review information

    Adjustable Bed Sleep System Double

    andlt;bodyandgt;   andlt;p align=andquot;centerandquot;andgt;Flex-A-Bed andlt;span lang=andquot;en-usandquot;andgt;Hi-Low Model 183andlt;/spanandgt;andlt;/pandgt; andlt;/bodyandgt;


    Medline Hospital bed

    Our mission is to provide quality medical products with superior value to healthcare providers and end users, improving patient care and the quality of peoples’ lives.

    COMPANY OVERVIEW

    Medline was founded in 1966, but its roots date back 100 years when A.L. Mills started Northwestern Garment Factory. Since then, the company has grown into America's largest privately-held national manufacturer and distributor of health care supplies and services. Medline provides products and services to the entire continuum of care, including hospitals, extended care facilities, surgery centers, commercial laundries, home care dealers, home care agencies, physician offices and other alternate care sites. Headquartered in Mundelein, IL, Medline has more than 6,800 employees in North America, including an 800 person dedicated sales force.

    BED, HI-LO, SINGLE CRANK, SEMI ELECTRIC

    Product #: GIC-5310
    Manufacturer: GUARDIAN
    Manufacturer #: IC-5310
    • * Latex Free

    Description

    Semi-Electric Beds: Guardian Semi-Electric Beds combine the convenience of electric head and knee positioning with the economy of manual hi/low adjustment. An ergonomic hand pendant positions the head and knee sections, and a manual crank changes the bed height. Features: Four-function hand pendant has raised function controls for easy operation and can be snapped onto the side rails for quick access. A single crank easily adjusts bed height of the GIC-5310; cranks both ends of the bed independently adjust the height of the GIC-5210 for easy trendelenberg and reverse trendelenberg positioning. Split-spring design ensures easy set-up and operation. Major bed components are functionally interchangeable with the industry leader. Welded steel construction and reinforced headspring provide added strength. Easy-release motor mounts provide trouble-free maintenance. Total weight capacity is 450lbs. (204kg) including patient, mattress, bedding and accessories. Generous lifetime warranty on all welds and two-year warranty on mechanical and electrical components. UL 962 and CAN/CSA C22.2 No. 68 approved. Semi-Electric Single Crank Hi/Lo Bed.

    Packaging Details

    UoM Conversion Net/Gross
    Weight(lbs)
    Volume
    (cubic ft)
    Dimensions(inch)
    L x W x H
    GTIN
    Each(EA) 1.0 Each 0.0 / 185.21 39.583 47.5 x 36.0 x 40.0 0016958677805



    Vision

    As the number of elderly anddisabled increases yearly, demand for well designed healthcare, mobilityand rehabilitation products are also increasing. In 1985 Merits Health Products was founded to design and manufacture innovative healthcare products for people who experience mobility or respiratory problems.

    Improving the quality of life for people everyday worldwide is what we strive for. The best products and services cannot materialize without the best team to back them up. Training, education and employee safety are all importantobjectives at Merits. A proud team is a productive team and a productive team helpsour company prosper.

    Merits Health Products logo, consisting of four red hearts, is a symbol of our commitment to provide products second to none. Four red hearts represent faithfulness, caring, love and untiring determination toward our goal of enhancing human life. We commit through dedication to continue our efforts in providing the best possible products and services available at the most economical cost to you, our valued customer. The emblem combined with our slogan, andquot;With you for lifeandquot;, demonstrates the business goal of Merits' soul.




    B210 Semi-Electric Bed (Hi-low hand crank)





    All the features of the Full Electric Bed except for hand crank to adjust bed frame height

    Technical Specs
    Height Overall
    Min. Max. Length Width
    16andquot;24.5andquot; 88andquot; 36andquot;

    Downloads
    B210 Owners Manual
    Downloads
    B210 Service Manual



    B310 Full Electric Bed


    Technical Specs
    Height Overall
    Min. Max. Length Width
    15andquot;23andquot; 88andquot;36andquot;


    Downloads
    B310 Owners Manual
    Downloads
    B310 Service Manual

    • Quiet, smooth operation and easy to set up
    • The easy-to-use hand pendant electrically controls the positioning of the upper body and knee sections of the bed frame to provide maximum comfort and convenience for the patient or caregiver
    • Side clips under angle iron store shaft when bed is unassembled
    • Easy to set up
    • Back and foot adjustment allow for an anatomically correct sleep surface
    • Channel frame construction provides superior strength and reduced weight
    • Junction box, head and foot ends and hand controls are interchangeable with Invacare
    • Heavy Duty, vinyl clad bed ends are attractive in any decor and easy to maintain
    • Zinc coated spring deck
    • Supports patients up to 450 lbs


    B3101 Full Electric Low Bed



    Technical Specs
    Height Overall
    Min. Max. Length Width
    12.5andquot;21andquot; 88andquot; 36andquot;

    Downloads
    B3101 Owners Manual
    Downloads
    B3101 Service Manual

    • Offering the same great quality and features as the other Merits Health Products electric home care beds, with a low height of only 10andquot;, injuries from falling out of bed are no longer a great concern
    • Bed height: Min 10andquot;, Max 17.25andquot; (at deck level)
    • Casters engage at lowest position for bed movement
    • Casters dis-engage when bed is elevated to dis-allow movement of bed
    • Head and foot sections adjust with quiet and strong motor
    • Headrest adjustable angle: 0° - 75°
    • Footrest adjustable angle: 0° - 23°
    • Supports patients up to 450 lbs.


    B3101 Full Electric Low Bed



    Technical Specs
    Height Overall
    Min. Max. Length Width
    12.5andquot;21andquot; 88andquot; 36andquot;

    Downloads
    B3101 Owners Manual
    Downloads
    B3101 Service Manual


    • Offering the same great quality and features as the other Merits Health Products electric home care beds, with a low height of only 10andquot;, injuries from falling out of bed are no longer a great concern
    • Bed height: Min 10andquot;, Max 17.25andquot; (at deck level)
    • Casters engage at lowest position for bed movement
    • Casters dis-engage when bed is elevated to dis-allow movement of bed
    • Head and foot sections adjust with quiet and strong motor
    • Headrest adjustable angle: 0° - 75°
    • Footrest adjustable angle: 0° - 23°
    • Supports patients up to 450 lbs.

    B211 One-motor Semi-Electric Bed
    Technical Specs
    Height Overall
    Min. Max. length Width
    15andquot;23andquot; 88andquot; 36andquot;


    Downloads
    B211 Owners Manual
    Downloads
    B211 Service Manual

    • Quiet, smooth operation
    • Interchangable headboard and footboard assembly
    • One motor provides adjustment for any positioning of the upper body and knee sections of bed frame
    • Built-in actuator junction box for head and foot controls
    • 450-lb weight capacity


    Bariatric

    B320 Full Electric Bariatric Bed


    Technical Specs
    Length 88andquot;
    Width 42andquot;
    Height 15-23andquot;
    Capacity 600lb

    Features
    • 600 lb Weight Capacity
    • Quiet, smooth operation
    • Heavy Duty Frame ensures strength and patient safety
    • All steel construction
    • Larger sleep surface that conventional bed
    • Split pan design with removable bed ends is easy to set-up
    • No tools necessary for set-up
    • Hand control (included) provides for multiple bed positioning for patients
    • Emergency manual crank included
    • Warranty: Welds: 1 year. Frame: 5 years
    • Mechanical and Electrical parts: 1 year


    Revolution Mobility

    Semi-Electric Bed Package- Spring Deck

    Highlights

    HCPCS Code E0260
    Weight Capacity 450 lbs

    FEATURES - BENEFITS

    • Quiet and smooth operation
    • Head and foot section adjust electronically with remote
    • Bed height adjustable by crank
    • Bed adjustments allow for anatomically correct sleep surface
    • Zinc coated spring deck
    • Easy to set up
    • Package includes: 36
    • Conveniently packaged in two cartons
    • Also available with half rails

    Semi-Electric Bed Package- Spring Deck Specifications

    MBED-450-L
    Bed Height (min) 16andquot;
    Bed Height (max) 21.25andquot;
    Overall Length 88.25andquot;
    Overall Width 36andquot;
    Weight Capacity 450 lbs
    Product Weight 166 lbs

    Full-Electric Bed Package

    Highlights

    HCPCS Code E0265
    Weight Capacity 450 lbs

    FEATURES - BENEFITS

    • Quiet and smooth operation
    • Head and foot section adjust electronically with remote
    • Bed height adjustable by crank or electronically
    • Bed adjustments allow for anatomically correct sleep surface
    • Zinc coated spring deck
    • Easy to set up
    • Package includes: 36
    • Conveniently packaged in two cartons
    • Also available with half rails

    Full-Electric Bed Package Specifications

    MBED-450-F
    Bed Height (min) 15.5andquot;
    Bed Height (max) 23andquot;
    Overall Length 89.25andquot;
    Overall Width 36andquot;
    Weight Capacity 450 lbs
    Product Weight 171 lbs

    Full-Electric Bariatric Bed Package

    Highlights

    HCPCS Code E0303
    Weight Capacity 600 lbs

    FEATURES - BENEFITS

    • Quiet and smooth operation
    • Heavy duty frame ensures strength and patient safety
    • Made of all steel
    • Hand control provides for multiple bed positions
    • Bed height adjustable by crank or electronically
    • Easy to set up with split pan design and removable bed ends
    • Package includes: 42
    • Conveniently packaged in two cartons
    • Also available with half rails

    Full-Electric Bariatric Bed Package Specifications

    MBED-600-I
    Bed Height (min) 18andquot;
    Bed Height (max) 26.25andquot;
    Overall Length 88andquot;
    Overall Width 42.25andquot;
    Weight Capacity 600 lbs
    Product Weight 281 lbs


    The Hospital Grade Valiant

    We know hospitals and other institutions have unique needs and requirements not common to the in-home setting. We also know that rising costs have kept some facilities from much needed replacement and/or additional beds. The Hospital Grade Valiant was designed to meet and exceed the demanding and rigid regulations of a hospital and yet be affordable. These beds have been tested and retested, making sure they pass the most stringent of hospital codes. The Hospital Grade Valiant is an excellent choice and a supreme value anywhere you need full function non-acute care beds.

    The Hospital Grade Valiant HD

    Transfer Master introduces our Hospital Grade Valiant Heavy Duty, five function bed. This bed features independent head, foot, hi-low, Trendelenburg and reverse Trendelenburg operation controlled by one easy-to-use hand control. The Valiant's sleek lines emphasize a fine furniture look creating a more comfortable atmosphere for the user, perfect for maternity wards, sleep centers and bariatric clinics.

    andquot;I have been disabled since 1997 from a spinal cord injury. For the first time in almost ten years, I am able to sleep through the night – eight hours plus. I love my Transfer Master bed!andquot;James W., Hyde Park, MA

    Standard Features

    The Hospital Grade Valiant (Model 312HSP) Standard Features:

    • Head, Foot and Hi-Low Adjustable
    • Trendelenburg and Reverse Trendelenburg
    • Weight capacity up to 600 pounds
    • Lowest setting 22 inches from top of mat to floor
    • Hi-Low raises up 10 inches
    • Orthopedic mattress, choice of cloth or vinyl
    • Powder coat finish on deck and trim
    • 5 Inch Swivel Lock Casters
    • Safety thermal overload protected motors
    • Electronics and motors have easy to service modular connections
    • Computer and Environmental Control compatible with serial port connector
    • Wall Bumpers and Catheter Hooks optional

    Model 312HSP/313HSP Available Sizes:

    • Twin Extra Long 38 by 80 inches
    • Twin Super Long 38 by 84 inches
    • Full Extra Long 53 by 80 inches
    • Full Super Long 53 by 84 inches
    • Queen 60 by 80 inches



    Hi - Low Beds

    Hi - Low Beds
    The Transfer Master New Valiant Hi-Lo Bed fits attractively into any home. The Valiant operates with four independent CSA-US approved motors allowing the bed to rise in multiple positions Bariatric not only applies to weight but also size. When a bed is needed other than a standard hospital bed of 36andquot; it is automatically put into the Bariatric category.

    When it comes to Bariatric Hospital Beds, a heavy duty extra wide hospital bed is covered if the patient meets one of the criteria for a fixed height hospital bed and the patient's weight is more than 350 pounds, but does not exceed 600 pounds.

    An extra heavy-duty hospital bed is covered if the patient meets one of the criteria for a hospital bed and the patient's weight exceeds 600 pounds.


    The Original Transfer Master

    The Original Transfer Master



    In 1969 man first landed on the moon, 24 years later we figured out how to independently transfer in and out of bed. The patented Original Transfer Master Hi-Low was the first bed built to help with transfers.

    The standard minimum height (from the top of the mattress to the
